Description
Reduce the outlet
Bring a 1-inch BSP tank connection down to a ¾-inch BSP female outlet with this two-piece plastic adapter kit.
A double-male tank connector joins to a separate reducing socket. The assembled fitting presents a 1-inch male thread at the tank end and a ¾-inch female socket at the outlet.
Back nut and two mounting washers included. Tank, tap, hose and additional sealing materials are separate.
How the parts connect
The socket reduces the outlet while the tank connector provides the mounting.
Tank connector
The connector has 1-inch BSP male threads at both ends. Its flange, washers and back nut allow a suitable through-wall mounting. For an existing threaded tank outlet, match the exposed male thread to a 1-inch BSP female connection.
Reducing socket
The separate socket has female threads at both ends: 1-inch BSP on the larger side and ¾-inch BSP on the smaller side. Screw its 1-inch side onto the tank connector’s remaining male end, with an appropriate seal at that joint.
Your chosen outlet
The free ¾-inch female end accepts a matching male-threaded fitting. A separately sold ¾-inch BSP male bib tap is one option. Check handle clearance, support and the hose connection your installation needs.
Mount the connector first
This photograph shows the 1-inch tank connector on its own, with the retaining nut removed to reveal the mounting parts. The separate reducing socket is shown attached in the illustration above.
For a suitable tank wall, seat one washer against the flange, pass the threaded stem through the prepared opening, then fit the other washer and nut on the opposite side. Keep the seating surfaces clean and avoid overtightening the plastic parts.
Check the actual connector against the wall thickness and opening before cutting. A BSP thread designation is not a drilling measurement.
After fitting the socket and chosen outlet, check the tank-wall seal and every threaded joint with water. The mounting washers do not seal the separate socket-to-connector or tap joints.
Questions about the reducer kit
What threads remain after the kit is assembled?
A 1-inch BSP male thread at the tank end and a ¾-inch BSP female outlet. The 1-inch female side of the reducing socket is used to join the socket to the tank connector; it is not the exposed tank connection of the assembled kit.
Is this one moulded reducer or two separate fittings?
It is a two-piece kit: one 1-inch BSP double-male tank connector and one reducing socket with 1-inch and ¾-inch BSP female threads. The tank connector also comes with a back nut and two mounting washers.
Does it include a tap or hose connector?
No. Choose a matching ¾-inch BSP male fitting separately for the female outlet. If you choose a tap, also check its hose connection and handle clearance. A tap, hose, tank and any additional thread-sealing materials are not included.
Do the mounting washers seal every connection?
No. They are provided for a suitable tank-wall mounting between the connector flange and back nut. The reducing socket and any tap or other fitting need appropriate sealing at their separate threaded joints. Inspect all connections after assembly.
Product information & technical details
| SKU | BUTT1BSPM001+SOC1-34 |
|---|---|
| Product type | |
| BSP thread size | 3/4", 1" |
| Thread gender | Male, Female |
| Colour | Black |
| Material | Plastic |
| Assembled tank connection | 1-inch BSP male |
|---|---|
| Assembled outlet | ¾-inch BSP female |
| Reducing socket connections | 1-inch BSP female × ¾-inch BSP female |
| Mounting parts | 1 back nut and 2 mounting washers |
| Supplied fittings | 1 double-male tank connector and 1 reducing socket |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
