Description
A male branch for your 20mm pipeline
Join two lengths of 20mm OD MDPE pipe and add a ¾-inch BSP male threaded branch at the same junction. The two grey compression nuts connect the straight run; the black branch projects at 90°.
Use that branch for a compatible female-threaded component. The illustration shows a separate female hose-tail adapter joining the tee to flexible hose, while the blue MDPE run continues through the fitting.
20mm is pipe OD; BSP is a nominal thread size. Not to scale.
Match the pipe. Match the thread.
Choose the straight run by pipe outside diameter: both compression sockets take 20mm OD plain MDPE pipe. A hose's internal diameter does not identify a suitable pipe for these sockets.
Choose the branch component by its female BSP thread: it must match the tee's external ¾-inch BSP male thread and its sealing arrangement. BSP is a nominal designation, not an inch-to-millimetre conversion.
If your existing component has a male thread, compare the 20mm tee with a ¾-inch BSP female branch instead.
Allow space for a supported junction
Keep both pipe ends aligned and avoid loading the threaded branch.
Prepare the MDPE ends
Isolate and depressurise the supply. Check for suitable 20mm OD pipe and prepare clean, square ends. Follow your pipe specification for any separate support liners.
Fit the female component
Use a compatible ¾-inch BSP female fitting on the branch. Follow its instructions for sealing and avoid overtightening or using the attached component as a lever on the plastic tee.
Secure and inspect
Follow the pipe and fitting instructions for insertion depth and tightening. Support the adjoining pipework and branch component. Check the PN10 designation against the complete assembly and service conditions, restore the supply gradually and inspect the joints.
Connection questions
Will the branch join directly to another male BSP fitting?
No. The tee's branch is male, so it needs a compatible ¾-inch BSP female component. Two external male threads do not screw directly together.
Is either grey socket a hose-tail connection?
No. Both are compression sockets for 20mm OD MDPE pipe. To connect hose at the threaded branch, choose a suitable separate female BSP adapter with a hose end that matches your hose. The adapter, hose and pipe shown are not included.
Product information & technical details
| SKU | MDPETEE20-34BSPM001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Male |
| MDPE size | 20mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Port layout | Straight run: two 20mm OD MDPE compression sockets. Branch at 90°: ¾-inch BSP male thread. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One tee. Pipe, adapters, hose, clips and any separate pipe liners are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
