Description
Restore control at your tank outlet
Replace a valve on a tank with a matching S100x8 connection. This plastic IBC valve combines a blue operating lever with a solid end cap, giving you an accessible shut-off control and a cover for the outlet when it is not connected.
The coarse tank connection is S100x8: nominal 100mm with an 8mm pitch. Check the tank thread, seal and available clearance before choosing a replacement; IBC valves are not all interchangeable.
One valve with end cap supplied. Tank, cage, hose and additional outlet fittings are not included.
Shut off the flow. Cover the opening.
The lever operates the valve; the removable solid cap covers its outlet. These have different jobs. Close the valve before removing the cap, and make sure the outlet is controlled before opening it.
This is a replacement valve assembly, not a garden hose kit. If you plan to attach a hose or pipe, check the valve's outlet connection and choose the appropriate separate fitting. The S100x8 designation identifies the tank connection; it should not be used to assume the size of an outlet adapter.
The genuine product photograph shows the capped assembly. Keep the lever accessible once fitted, with enough space around it to operate and remove the cap.
Three checks before replacement
Match the tank connection
Compare the actual thread diameter, pitch and sealing arrangement with the old valve. Check the mounting recess and lever clearance, rather than choosing by tank capacity alone.
Drain and isolate first
Empty and safely isolate the tank before removing its valve. Follow the tank manufacturer's fitting guidance, inspect the seal and engage the thread squarely without forcing it.
Check the fitted assembly
Check the valve operation, cap and connection for leakage before returning the tank to use. Support any attached pipework so its weight does not strain the valve.
Choosing the right replacement
Will this fit an S60x6 tank outlet?
No. S100x8 is a different, larger coarse connection. Check your tank's actual thread before ordering. You can compare the S100x8 fittings range when planning other connections.
Can I use it for drinking water or chemicals?
No drinking-water approval, chemical-compatibility specification, pressure rating or temperature limit has been confirmed for this valve. Check the requirements of your tank and intended liquid before choosing it; the included cap does not establish suitability for a particular service.
Product information & technical details
| SKU | IBCS100X8VALVE001 |
|---|---|
| Product type | |
| Thread gender | Male, Female |
| IBC thread size | S100X8 (4") |
| Colour | White |
|---|---|
| Material | Plastic |
| Operating control | Blue on/off lever |
| Supplied | One valve assembly with solid end cap |
