Description
A threaded branch for 25mm pipe
Use this 25mm MDPE tee with a 1-inch BSP female branch where a screw-in component needs to meet your pipework. The two grey compression nuts connect the straight run; the black internally threaded socket forms the branch at 90°.
The example shows a separate male hose-tail adapter joining flexible hose to the branch, while blue MDPE pipe continues through the two compression connections. It makes the three different connection points easy to identify before ordering.
25mm is pipe OD; BSP is a nominal thread size. Not to scale.
Two sizes with different meanings
25mm is the MDPE pipe outside diameter. Both grey compression sockets take plain 25mm OD pipe. Check the outside of the pipe, rather than its internal bore or the width of the nut.
1-inch BSP is the nominal branch thread size. The female thread is inside the black socket and accepts a compatible male-threaded component. Check the mating part's thread specification and sealing arrangement; it is not a connection for plain 1-inch hose.
If all three connections need to take 25mm MDPE pipe, choose the 25mm equal compression tee instead.
Plan the branch and its support
Allow access to both nuts and leave room for the screw-in component.
Prepare the pipework
Isolate and depressurise the supply. Prepare clean, square ends on suitable 25mm OD MDPE pipe. Follow your pipe specification for any separate support liners.
Fit the male component
Choose a compatible 1-inch BSP male fitting and use the sealing arrangement specified for it. Avoid overtightening into the plastic socket or using an attached component as a lever.
Secure the assembly
Follow the pipe and fitting instructions for insertion depth and tightening. Support the adjoining pipes and branch component independently. Check the PN10 designation against the complete assembly and service conditions, then restore the supply gradually and inspect each joint.
Before you connect
Can I push 1-inch hose straight into the branch?
No. The branch is an internal BSP screw thread, not a hose tail. For a hose connection, use a separate compatible 1-inch BSP male adapter with a hose end that matches your hose.
What comes with this fitting?
One tee with two 25mm compression connections and a 1-inch BSP female branch. The pipes, brass adapter, hose and clips in the illustration are not included, nor are any separate pipe liners required for your chosen pipe.
Product information & technical details
| SKU | MDPETEE25-1BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 1" |
| Thread gender | Female |
| MDPE size | 25mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Port layout | Straight run: two 25mm OD MDPE compression sockets. Branch at 90°: 1-inch BSP female thread. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One tee. Pipe, adapters, hose, support clips and any separate pipe liners are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
