Description
Connect your pipe run to a male fitting
Make the transition from 32mm MDPE pipe to a matching ¾-inch BSP male connection. The pipe enters the grey compression nut; the male component screws inside the black female socket.
The illustration shows this straight adapter connected to a separate brass elbow. One adapter is supplied. Pipe, elbow and support clip are not included.
32mm pipe. ¾-inch BSP thread.
Choose the compression end by pipe outside diameter. It takes suitable 32mm OD MDPE. Measuring the pipe bore or the grey nut will not identify the correct pipe size.
Choose the threaded end by its BSP size and gender. The recessed female socket needs a compatible ¾-inch BSP male fitting. That male thread measures approximately 26.4mm across its outer crests. The figure on the photo identifies the matching male thread, not the female socket’s bore or a unit conversion.
Check thread form and sealing requirements too. Compare other combinations in our MDPE straight joiners and threaded adapters.
Prepare the pipe and threaded joint
Allow space around the grey nut and support both sides of the connection.
Check the pipe end
Isolate and depressurise the supply. Prepare a clean, square end on suitable 32mm OD MDPE pipe and check whether a separate pipe liner is needed.
Protect the female socket
Start the matching male thread squarely. Follow the fittings’ sealing and tightening instructions without forcing the thread or overtightening the plastic socket.
Inspect both connections
Keep pipe strain off the adapter. Confirm the PN10 designation suits the complete assembly and service conditions, then restore the supply gradually and check both joints.
Confirm the connection before ordering
Will this fit a ¾-inch BSP female outlet?
No. This adapter also has a female socket and needs a matching male fitting. For a female outlet, choose an appropriate male-threaded adapter.
Does the 26.4mm label mean it takes 26mm pipe?
No. The compression end is for 32mm outside-diameter MDPE pipe. The 26.4mm figure identifies the approximate outside diameter of the matching ¾-inch BSP male thread.
Product information & technical details
| SKU | MDPESTR32-34BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Female |
| MDPE size | 32mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Connection | 32mm outside-diameter MDPE compression socket × ¾-inch BSP female thread. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One adapter. Pipe, elbow, support clip and any separate pipe liners or thread-sealing materials are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
