Description
Bring your pipe run to a threaded port
This straight adapter takes 25mm MDPE pipe at its grey compression end and connects to a matching ¾-inch BSP female fitting using the projecting black male thread.
Use it where plain pipe meets a compatible threaded component. One adapter is supplied; the pipe, elbow and support clip in the illustration are separate items.
Check pipe diameter and thread size separately
The pipe is measured on the outside. Choose this compression end for 25mm OD MDPE. The grey nut’s overall width and the pipe’s internal bore are different measurements.
The male thread is ¾-inch BSP. It measures about 26.4mm across its outer crests, rather than 19.05mm. BSP is a nominal thread sizing system, so match the female port’s stated size, thread form and sealing requirements.
Need another pipe or thread combination? Compare the MDPE straight couplings and threaded adapters before ordering.
Keep the connection accessible and supported
Leave space around the compression nut and avoid strain on the plastic spigot.
Prepare the pipe
Isolate and depressurise the supply. Prepare a clean, square end on suitable 25mm OD MDPE pipe, and check whether a separate pipe liner is required.
Align the threaded parts
Start the male thread squarely in the matching female port. Follow the mating components’ sealing and tightening guidance; do not force a mismatched thread or overtighten the plastic end.
Check the assembly
Support adjoining components. Confirm the PN10 designation is suitable for the whole system and service conditions, then restore the supply gradually and inspect both joints.
Choose the right type of join
Will this connect directly to a male-threaded outlet?
No. The adapter has a male thread and needs a matching ¾-inch BSP female port. A male-threaded outlet requires an appropriate female adapter instead.
Is the 25mm end for ordinary flexible hose?
It is a compression connection for 25mm outside-diameter MDPE pipe, not a hose tail selected by hose bore. Use a fitting suited to your pipe or hose type.
Product information & technical details
| SKU | MDPESTR25-34BSPM001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Male |
| MDPE size | 25mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Connection | 25mm outside-diameter MDPE compression socket × ¾-inch BSP male thread. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One adapter. Pipe, elbow, support clip and any separate pipe liners or thread-sealing materials are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
