Description
A female socket for your threaded connection
Connect a 25mm MDPE pipe run to a matching ¾-inch BSP male fitting. The grey compression end receives the pipe; the internal thread inside the black socket receives the male component.
This is one straight adapter. The illustrated elbow, pipes and support clip show how the transition fits into a system and are not included.
Two sizes, two different measurements
25mm is the pipe outside diameter. Check the exterior of your MDPE pipe, rather than its internal bore or the width of the compression nut.
¾-inch BSP is the female thread size. Its matching male thread measures about 26.4mm across the outer crests. That figure identifies the nominal BSP size; it is not the adapter’s female bore or a direct conversion of ¾ inch to millimetres.
Match thread form and sealing requirements too. For other combinations, browse the MDPE straight joiners and threaded adapters.
Plan access around the connection
Leave room to assemble the joint and support the adjoining pipework.
Prepare the pipe end
Isolate and depressurise the supply. Prepare suitable 25mm OD MDPE pipe with a clean, square end, and check whether a separate pipe liner is required.
Start the thread squarely
Follow the mating fittings’ sealing and tightening instructions. Avoid forcing a mismatched thread or overtightening the plastic female socket.
Support and check
Keep strain off the adapter. Check the PN10 designation against the complete assembly and service conditions, then restore the supply gradually and inspect both joints.
Check the fit before you order
Does this fit a ¾-inch BSP female outlet?
No. This adapter also has a female socket, so it needs a compatible ¾-inch BSP male connection. Choose the appropriate male-threaded adapter for a female outlet.
Is this a connector for two plain pipe ends?
No. It has one MDPE compression end and one threaded socket. To join two plain 25mm MDPE pipe ends, choose a suitable 25mm equal compression coupling.
Product information & technical details
| SKU | MDPESTR25-34BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Female |
| MDPE size | 25mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Connection | 25mm outside-diameter MDPE compression socket × ¾-inch BSP female thread. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One adapter. Pipe, elbow, support clip and any separate pipe liners or thread-sealing materials are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
