Description
From MDPE pipe to a male-threaded fitting
This straight adapter brings a 20mm MDPE pipe into a ¾-inch BSP male connection. The grey compression end receives the pipe; the opposite black socket has the internal female thread.
Use it where the pipe and mating fitting need to meet in line. One adapter is supplied, with the separate valve and pipe shown only to explain the connection.
Match two different measurements
Pipe end: 20mm outside diameter. Measure across the outside of your MDPE pipe. The bore and the width of the grey nut are different dimensions.
Threaded end: ¾-inch BSP female. Choose a mating ¾-inch BSP male fitting with an external thread. BSP is a nominal pipe-thread size, not a 19.05mm opening or a ¾-inch hose connection.
For another pipe or thread size, compare the MDPE straight joiners and adapters and check both ends before ordering.
Plan a supported connection
Leave access to assemble and inspect both ends without straining the fitting.
Prepare the MDPE pipe
Isolate and depressurise the supply. Prepare a clean, square pipe end and follow the insertion guidance. Check whether the pipe needs a separate liner.
Protect the female socket
Confirm the mating thread and specified sealing method. Keep the threads aligned and follow the tightening guidance without overtightening the plastic socket.
Inspect the assembly
Support the adjoining pipework, restore the supply gradually and check the joints. Assess the PN10 designation alongside the complete system and its service conditions.
Before you choose
Will this join two plain 20mm pipe ends?
No. It has one pipe compression socket and one threaded socket. For two plain MDPE pipe ends, choose an equal compression joiner in the correct diameter.
Is the black end a hose connector?
It is a ¾-inch BSP female threaded connection, not a hosetail or a quick-connect socket. Its mating part needs a matching male BSP thread.
Product information & technical details
| SKU | MDPESTR20-34BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Female |
| MDPE size | 20mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Connection | 20mm outside-diameter MDPE compression socket × ¾-inch BSP female thread. |
| Pressure designation | PN10. Check the complete assembly and service conditions before use. |
| Pack contents | One adapter. Pipe, valve, support clip and any separate pipe liner or sealing materials are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
