Description
From MDPE pipe to a threaded connection
Bring a 20mm MDPE pipe run to a compatible threaded outlet with this straight adapter. The grey compression end receives the pipe, and the black 1-inch BSP female end screws onto a matching male fitting.
One adapter provides the transition. Pipe, valve and support clip are shown for context and are not included.
Match the pipe and the thread
The compression socket is sized for 20mm pipe outside diameter. Measure the pipe exterior, rather than its internal bore or the width of the grey nut.
The other connection is an internal female thread. It needs a 1-inch BSP male mating part. BSP sizes are nominal: the 1-inch designation is not a 25.4mm socket measurement. Confirm the thread type and sealing arrangement as well as the size.
Prepare both connections
Check fit and assembly requirements before installing the adapter.
Prepare the MDPE pipe
Isolate and depressurise the supply. Prepare a clean, square pipe end and check whether your pipe and fitting combination requires a separate liner.
Assemble the threaded end
Use the sealing method specified for the mating fittings. Keep the threads aligned and follow the fitting guidance for tightening; avoid forcing or overtightening the plastic socket.
Support and inspect
Support the adjoining pipe and valve without placing strain on the adapter. Restore the supply gradually and check both joints. Assess the PN10 designation alongside the complete system and service conditions.
Before you order
Does the grey nut take a threaded fitting?
No. The grey nut belongs to the compression connection for 20mm OD MDPE pipe. The 1-inch BSP female thread is at the opposite, black end.
What if I need a different pipe or thread size?
Choose an adapter that matches both connections. Compare the MDPE straight joiners and threaded adapters before ordering; a similar-looking fitting can have a different pipe diameter or BSP size.
Product information & technical details
| SKU | MDPESTR20-1BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 1" |
| Thread gender | Female |
| MDPE size | 20mm |
| Colour | Black, Grey |
|---|---|
| Material | Plastic |
| Connection | 20mm outside-diameter MDPE compression socket × 1-inch BSP female thread. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One adapter. Pipe, valve, support clip and any separate pipe liner or sealing materials are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
