Description
Pipe meets thread
Add a controllable connection between your 25mm MDPE pipe and a compatible male-threaded component. This 25mm stop valve has one compression socket and a ¾-inch BSP female end, operated by its black lever.
The installed example puts blue MDPE pipe above the grey nut and a separate brass male-to-hosetail adapter below the black female socket. The hose connects through that adapter, with supports for the pipe and hose.
Connection layout; not to scale.
Two connection types
The grey socket takes 25mm outside-diameter MDPE pipe. Measure across the plain pipe end, rather than using its internal bore or the width of the nut.
The black end has an internal ¾-inch BSP thread. Choose a compatible male BSP component and the appropriate sealing arrangement. BSP is a nominal thread designation, not a 19.05mm pipe or hose measurement.
For a hose connection, the separate male adapter also needs the correct hose end. Flexible hose does not push directly into the female screw thread.
Leave room for the lever
Allow room to move the lever and support the adjoining components before tightening the joints.
Prepare the pipe
Isolate the upstream supply and depressurise the line. Use a clean, square-cut 25mm OD MDPE end and follow the pipe instructions for any separate support liner.
Match the male fitting
Fit a compatible ¾-inch BSP male component to the female end. Follow its sealing instructions and avoid overtightening or using the attached fitting to twist the valve body.
Support and check
Follow the fitting instructions for pipe insertion and compression-nut tightening. Support pipework and attached equipment independently. Check the PN10 designation against the complete system and service conditions, then restore the supply gradually and inspect the joints and valve operation.
Check the end connections
Can I push hose directly into the black end?
No. The black end is a female BSP screw thread. Use a separate compatible ¾-inch BSP male adapter with the right connection for your hose. One valve is supplied; adapters, hose, pipe, clips and any separate pipe liners are not included.
What if I need 25mm pipe on both sides?
Choose the 25mm stop valve with two compression ends instead. This version has only one MDPE pipe socket; the other end is female-threaded.
Product information & technical details
| SKU | MDPEVALVE25-34BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Female |
| MDPE size | 25mm |
| Colour | Black, Grey |
| Material | Plastic |
|---|---|
| Connections | One 25mm OD MDPE compression socket and one ¾-inch BSP female threaded end. |
| Operation | Manual lever-operated on/off control. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One valve. Adapters, pipe, hose, clips and any separate pipe liners are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
