Description
Connect three pipes
Join a 20mm MDPE pipe run to a 25mm branch at 90°. The two opposite sockets take 20mm outside-diameter pipe, while the branch socket takes 25mm outside-diameter pipe.
All three ends are compression connections for plain pipe. The illustration shows the tee within supported pipework; pipes and mounting clips are separate items.
Pipe outside diameters. Schematic, not to scale.
Check all three ports
The port order is 20mm-25mm-20mm: end, branch, end. The straight-through pipe sizes match one another; the branch is larger.
Measure the outside diameter of each MDPE pipe. These millimetre sizes do not refer to pipe bores or the outside width of the grey nuts.
This tee connects the three runs without specifying a fixed flow direction. It has no valve or shut-off function. Browse the MDPE tee splitters for other connection sizes.
Plan access around the tee
Leave room to fit all three pipes and reach each compression nut.
Prepare the correct sizes
Isolate and depressurise the supply. Prepare clean, square ends on two suitable 20mm OD MDPE pipes and one 25mm OD pipe. Check whether their specifications require separate liners.
Fit the three sockets
Place each pipe in its matching compression end. Follow the pipe and fitting instructions for insertion and tightening, keeping the straight run aligned and the branch free from strain.
Support and inspect
Support the adjoining pipework so its weight does not rest on the tee. Check the PN10 designation against the complete assembly and service conditions, then restore the supply gradually and inspect all three joints.
Choose the right layout
Are all three sockets 20mm?
No. The two opposite sockets accept 20mm OD pipe, and the branch accepts 25mm OD pipe. Choose a 20mm equal tee when all three pipes have the same 20mm outside diameter.
Can I screw a tap directly into the branch?
The branch is a compression socket for plain 25mm OD pipe, not a BSP threaded outlet. A threaded tap needs an appropriate pipe-to-thread adapter, or a tee with the correctly sized threaded branch.
Product information & technical details
| SKU | MDPETEE20-25-20001 |
|---|---|
| Product type | |
| MDPE size | 20mm, 25mm |
| Colour | Black, Grey |
| Material | Plastic |
|---|---|
| Port layout | Straight run: 20mm OD × 20mm OD. Branch at 90°: 25mm OD. All three connections are MDPE compression sockets. |
| Pressure designation | PN10. Confirm suitability for the complete assembly and service conditions. |
| Pack contents | One tee. Pipe, support clips and any separate pipe liners are not included. |
