Description
Pipe to female BSP
Bring a 25mm MDPE pipe run to a component with a 1-inch male BSP thread. This elbow combines one compression socket with an internal female BSP thread, turning the connection through 90°.
The grey nut connects the pipe. The black socket accepts the matching male thread, making the two ends easy to identify before you assemble the pipework.
One adapter supplied. The illustration leaves the female socket open to show the connection; pipe and support clip are separate.
Match the pipe and threaded component
Each end uses a different size convention. Check both before ordering.
Pipe end: 25mm MDPE
The compression socket takes 25mm outside-diameter MDPE pipe. Check the plain pipe end, rather than measuring the nut. This connection is not a hose tail for pushing a flexible garden hose over.
Threaded end: 1-inch BSP female
The internal thread accepts a compatible 1-inch male BSP component. BSP is a nominal thread size, so it is not a direct conversion from one inch to millimetres. Open “What is BSP?” in the product information below for thread-identification help.
Allow space around the elbow
Plan access to both connections before fixing the pipe run in place.
Prepare the pipe
Isolate and depressurise the supply. Cut sound pipe square and clean the end. Follow the fitting guidance for insertion depth, assembly and any pipe-liner requirement.
Start the thread squarely
Match the male component to the female BSP socket and use the sealing method appropriate for that joint. Avoid cross-threading or overtightening the plastic fitting, and leave room to access the compression nut.
Support and inspect
Support the pipe and mating component independently so their weight does not strain the elbow. Restore the supply gradually and inspect both joints. Operating conditions must suit the complete installation.
Before you connect it
How do I identify the female BSP end?
The female connection is the black socket with threads on its inside. It accepts a matching male BSP component with external threads. The grey nut belongs to the separate 25mm pipe compression connection.
Does 1-inch BSP mean the pipe must be one inch wide?
No. This version takes 25mm outside-diameter MDPE pipe at the compression end and a nominal 1-inch BSP male component at the threaded end. Check each connection independently; the two labels are not interchangeable measurements.
Product information & technical details
| SKU | MDPEELB25-1BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 1" |
| Thread gender | Female |
| MDPE size | 25mm |
| Colour | Black, Grey |
| Material | Plastic |
|---|---|
| Bend angle | 90°. |
| Connections | 25mm MDPE compression × 1-inch BSP female. |
| Pressure designation | PN10. |
| Pack contents | One elbow adapter. Pipe, clips, mating fittings, seals and pipe liners are not included. |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
