Description
Connect to a female BSP outlet
Add a garden hose connection to a matching threaded fitting with this ¾-inch BSP male adapter. Its chrome-finished zinc body joins a broad male screw thread to a narrow male garden quick-connect plug.
The illustration shows the threaded end seated inside a separate female elbow. The plug stays accessible, ready for a compatible female socket on the end of your hose.
One adapter supplied. Receiving fittings, pipework, hose and female hose connectors are separate.
Match each end separately
The broad end has an external ¾-inch BSP thread. It needs a matching female receiving thread. Two male threaded fittings cannot screw together, and this adapter does not replace a female adapter fitted over a male tap spout.
The other end is a garden quick-connect plug. A compatible female hose socket slides over it and locks in place. The black O-ring seals at that socket interface; it is not the seal for the separate BSP joint.
Your hose size is a third consideration. The optional chrome connector above grips ½-inch hose. That hose measurement is independent of the adapter’s ¾-inch BSP thread, so choose both connections for their own purpose.
Assemble, connect and check
Start with the thread
Shut off the water and release pressure. Check the receiving fitting and use the sealing method appropriate to its BSP joint. Start the thread squarely by hand; avoid forcing or overtightening it, especially into plastic.
Attach the hose socket
Inspect the black plug ring and mating socket for dirt or damage. Seat the compatible female connector fully, then open the supply gradually and check both connections before use.
Release at the connector
Turn off the supply and relieve pressure before uncoupling. Operate the separate socket’s release mechanism, leaving the threaded adapter assembled. Clean away grit and drain exposed fittings before freezing weather.
Before you order
Will this screw onto a normal male tap thread?
No. This adapter also has a male thread. It screws into a matching ¾-inch BSP female fitting. Choose a female threaded adapter for a matching male tap outlet.
Does the chrome finish mean it is brass?
No. This version has a zinc-alloy body with a chrome finish. Nickel-plated brass and other material versions are different products.
Do I twist the adapter to disconnect the hose?
No. Release the hose through the separate female connector’s mechanism. The adapter is a fixed plug and does not shut off the water automatically; isolate the supply and release pressure first.
What arrives with this adapter?
One chrome-finished zinc adapter with its black plug O-ring. The elbow, pipework, hose and female connector shown or discussed are not included.
Product information & technical details
| SKU | TAPCON34BSPM001ZC |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Male |
| Colour | Silver |
| Material | Chrome |
|---|---|
| Body and finish | Zinc alloy with chrome finish |
| Garden connection | Male quick-connect plug with black O-ring |
| Supplied quantity | One adapter; receiving fitting, pipework, hose and female hose socket sold separately |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
