Description
Connect 75mm hose to your pond equipment
This straight adapter joins suitable 75mm pond hose to a matching 3-inch BSP female connection.
A broad male thread fits the equipment end, with a single-size ribbed hosetail for the hose run.
One black plastic adapter supplied. Hose, clips and sealing accessories are separate.
Two connection sizes on one adapter
The ribbed end is sized for suitable 75mm internal-bore hose. The threaded end is 3-inch BSP male, shown at 87.88mm across in the reference photograph.
Check the hose and equipment specifications separately. A matching hose bore does not establish the thread size, and the nominal BSP label is not a hose measurement.
Plan the hose connection
Leave space to assemble, support and inspect both joints.
Start at the equipment port
Confirm a 3-inch BSP female connection. Follow the equipment’s sealing and tightening guidance for plastic fittings. The hex shoulder is fixed to the body; it is not a swivel collar.
Fit the hose and clip
Check the 75mm hose bore and wall profile. Size the securing clip around the outside of the seated hose. The suggested 70-90mm range is suitable only if the fitted diameter falls within it and the clip suits your hose.
Support the larger hose run
Arrange a gradual bend without sideways pull on the threaded port. Support the hose and keep access to the clip. Inspect both connections with water before covering the route or making the joint difficult to reach.
Questions about the 75mm adapter
Does this fit a 3-inch BSP male outlet?
This adapter already has a male thread. It needs a matching 3-inch BSP female port or fitting at the equipment end. Check the equipment specification before ordering; a male outlet will require a different connection.
Why does the thread photo say 87.88mm rather than 75mm?
The two numbers refer to different ends. The hosetail is intended for suitable 75mm-bore hose. The external thread is nominal 3-inch BSP, labelled 87.88mm across in the reference photo. Use the stated BSP thread size to match equipment, and the metric internal bore to choose hose.
Which hose clip should I order?
Choose the clip for the outside diameter of the hose once fitted over the barb, and check the clip style suits the hose wall. The 70-90mm clip range suggested on this page is relevant only if your fitted diameter falls within that range. A 75mm hose bore alone does not establish the clip size.
Can I turn the hose end independently of the thread?
The adapter has a fixed body rather than an independent swivel collar. Plan assembly access and hose direction before tightening. Follow the equipment’s fitting instructions, avoid twisting or loading the port with the hose run, and leave both joints accessible for inspection.
Product information & technical details
| SKU | POND75B-3BSPMSTR001 |
|---|---|
| Product type | |
| BSP thread size | 3" |
| Thread gender | Male |
| Barb size | 75mm (3") |
| Colour | Black |
| Material | Plastic |
|---|---|
| Connection layout | Straight 75mm hosetail to 3-inch BSP male thread |
| External thread diameter | Approximately 87.9mm; reference photo labelled 87.88mm |
| Body design | Fixed hex shoulder; single-size ribbed hosetail |
| Contents | One adapter; hose, clips and equipment not included |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
