Description
A straight adapter for your 40mm hose run
Join suitable 40mm pond hose to equipment with a matching 1¼-inch BSP female port.
The single-size ribbed hosetail and external male thread give you two distinct connections to check when choosing the fitting.
One black plastic adapter supplied. Hose, clips and sealing accessories are separate.
Check the size at each end
The hose connection is for a suitable 40mm internal bore. Check that metric size when comparing hoses: the separate 38mm range may also be called 1½-inch.
The equipment connection is 1¼-inch BSP male, with an external thread reference of approximately 41.91mm. The dimension photograph shows the 80mm overall length and 50mm hosetail section in two views of one adapter.
Give the fitting room to work
Plan the hose, clip and equipment connection together.
Match the BSP port
Confirm a 1¼-inch BSP female port before assembly. Follow its sealing method and tightening guidance for plastic fittings. The hex shoulder is part of the adapter body; it is not an independent swivel collar.
Check hose and clip fit
Choose suitable 40mm-bore hose and check its wall profile against the hosetail. Select a securing clip for the hose’s fitted outside diameter. Hose and clips are sold separately from this bare adapter.
Support a gradual bend
Leave room beyond the hosetail for the hose to curve gently. Support the run without twisting or pulling on the port, keep both joints accessible and inspect the completed assembly with water before concealing it.
Questions about the 40mm adapter
Will a hose labelled 1½-inch fit this adapter?
Check the metric internal bore. Both 38mm and 40mm pond hoses can carry a nominal 1½-inch trade label, but they are separate sizes in this range. This adapter is intended for suitable 40mm-bore hose. Match the hose bore and wall profile to the hosetail; an inch label alone is not enough to establish the fit.
Why does a 40mm hosetail have a 1¼-inch thread?
The hose end and the equipment end are separate connection specifications. This version combines a 40mm hosetail with a nominal 1¼-inch BSP male thread, shown at approximately 41.91mm externally. It needs a matching 1¼-inch BSP female port. Choose the hose bore and the BSP thread independently when matching a pump, filter or other fitting.
Does the adapter include the hose clip?
No. This listing supplies one bare black plastic adapter. Choose the hose and clip separately, checking the hose’s construction and the outside diameter once it is seated on the barb. A clip’s size relates to the outside of the fitted hose, not simply its 40mm internal bore. Follow the hose and clip instructions when securing the joint.
Is 80mm enough space for the complete connection?
The 80mm dimension is the adapter’s overall length, including its 50mm hosetail section. The finished installation also needs room for thread engagement, hose seating, a securing clip and a broad hose bend. Plan the full route and keep the joints accessible. Support the hose so its weight and sideways pull do not load the plastic equipment connection.
Product information & technical details
| SKU | POND40B125BSPMSTR001 |
|---|---|
| Product type | |
| BSP thread size | 1.25" |
| Thread gender | Male |
| Barb size | 40mm (1.5") |
| Colour | Black |
| Material | Plastic |
|---|---|
| Connection layout | Straight 40mm hosetail to 1¼-inch BSP male thread |
| Overall length | 80mm |
| Hosetail section length | 50mm |
| External thread diameter | Approximately 41.91mm; nominal 1¼-inch BSP |
| Contents | One adapter; hose, clips and equipment not included |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
