Description
From a threaded port to your 32mm hose
A straight black plastic adapter for suitable 32mm-bore pond hose and a matching 1-inch BSP female connection.
The single-size ribbed hosetail carries the hose. The other end has an external male thread, with a hexagonal shoulder between the two.
One adapter supplied. Hose and clips are sold separately.
Two sizes to check, one fitting to position
The 32mm hose connection and 1-inch BSP thread describe different ends. The thread’s external diameter is approximately 33.25mm in the dimension photo; it is not a 25mm hose connection.
Use the 70mm overall length and 40mm hosetail section to plan access. Leave extra room for the hose bend and clip. The image shows two views of one adapter.
Plan the connection before you fit it
Check the port, the hose and the space around them.
Identify the female port
Confirm a compatible 1-inch BSP female connection. Follow its sealing requirements and tightening guidance for plastic fittings. The adapter has no swivel collar to turn independently of the body.
Choose the hose and clip
Use suitable 32mm internal-bore hose that seats correctly on the barb. Select the securing clip from the fitted hose outside diameter and wall profile; hose and clips are separate.
Keep the run supported
Position the hose without a sharp bend or sideways load on the port. Secure it according to the hose instructions, then inspect both the threaded joint and hose joint with water before covering them.
Choosing the 32mm male-threaded adapter
Why is the hose 1¼-inch but the thread 1-inch?
The 32mm hosetail is for suitable hose with a 32mm internal bore, commonly called 1¼-inch. BSP uses a separate nominal pipe-thread convention: this adapter has a 1-inch BSP male thread, approximately 33.25mm externally in the dimension photo. Match the hose bore and the equipment’s stated thread size separately.
Will it fit a 1-inch male equipment outlet?
No. This adapter has an external male thread, so it needs a compatible 1-inch BSP female port or fitting. If your pump or filter outlet is male, select a correctly sized female-threaded hosetail instead. Check the equipment connection specification and its required seal; a similar-looking connector is not enough to establish the fit.
How much space do I need beyond the equipment port?
The adapter is 70mm long overall, with a 40mm hosetail section shown from the shoulder towards the hose end. These are fitting dimensions, not the complete installed clearance. Allow additional space to seat and secure the hose and form a gentle supported bend without pulling sideways on the port. The photograph shows two views of one adapter.
Are a seal and hose clip included?
One bare adapter is supplied; hose, clips and sealing accessories are not included. Use the sealing arrangement specified for the matching equipment connection. Choose a hose clip from the fitted hose outside diameter and wall construction, not the 32mm bore alone, then check both completed joints with water and retain access for inspection.
Product information & technical details
| SKU | POND32B1BSPMSTR001 |
|---|---|
| Product type | |
| BSP thread size | 1" |
| Thread gender | Male |
| Barb size | 32mm (1.25") |
| Colour | Black |
| Material | Plastic |
|---|---|
| Connection layout | Straight 32mm hosetail to 1-inch BSP male thread |
| Overall length | 70mm |
| Hosetail section length | 40mm |
| External thread diameter | Approximately 33.25mm; nominal 1-inch BSP |
| Contents | One adapter; hose, clips and equipment not included |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
