Description
Finish the line at the last planting bed
A watering supply needs a defined endpoint. This compact barbed plug closes the end of a suitable LDPE pipe run, ready for water to be delivered through the outlets elsewhere in the system.
The Antelco 44565 fits nominal 19mm-bore LDPE irrigation tube. Its insertion tail sits inside the tube, leaving the ribbed head and stop flange outside.
One end plug supplied. The pipe, retaining clip and garden setting shown are not included.
A compact closure for LDPE pipe
The single barbed tail goes into the tube; the wider flange marks the end of the insertion section. The closed head finishes the run without adding a second hose connection, threaded socket or shut-off lever.
Choose it for low-density polyethylene (LDPE) irrigation tubing with the correct nominal 19mm internal diameter. Outside-diameter pipe labels are a different measurement, and a ¾-inch BSP fitting is a different connection altogether.
UV-stabilised plastic supports outdoor irrigation use. The operating limit is 300kPa (3bar); the tube, joints and other components must also suit the pressure. The plug does not regulate the water supply.
Fit a sound endpoint
Prepare the tube end
Isolate the supply and release pressure. Check the tube type and bore, then prepare a clean, undamaged end following the tubing system’s instructions.
Seat and retain the plug
Push the tube fully over the insertion tail towards the stop flange. Use compatible retention where your installation requires it; choose any clip to suit the outside diameter of the assembled joint.
Check before watering
Support the pipe so it does not pull on the plug. Restore water gradually within the system’s limits and inspect the endpoint. Turn off and depressurise before adjusting or removing the fitting.
Choosing the right end fitting
Will this fit pipe labelled 19mm outside diameter?
Not necessarily. This plug is for suitable LDPE tube with a nominal 19mm internal diameter. Confirm the tube bore and its fitting compatibility rather than matching the outside-diameter number alone.
Can I attach another hose to the end?
No. The head is closed. Use an appropriate straight joiner if you want to extend the run, or the correct branch fitting if you want to split it. This plug is for terminating one tube end.
Is this a drain or flushing valve?
No. There is no opening control. If the system needs regular flushing, plan suitable flushing access separately and follow the irrigation system’s maintenance instructions. Never remove the plug while the line is pressurised.
Does it come with the retaining clip?
No. One Antelco 44565 plug is supplied. The installation image illustrates a separate clip; pipe and clips are not included. Follow the tube system’s retention requirements and match the clip type and fitted outside diameter.
Product information & technical details
| SKU | A44565-PLUG19B001 |
|---|---|
| Product type | |
| Barb size | 19mm (3/4") |
| Colour | Black |
| Material | Plastic |
| Manufacturer / model | Antelco 44565 |
| Connection function | Barbed tube-end closure |
|---|---|
| Tube type | Suitable 19mm internal-diameter LDPE irrigation tube |
| Material specification | UV-stabilised plastic |
| Maximum operating pressure | 300kPa (3bar); observe the complete system’s limits |
| Supplied quantity | One end plug; pipe and retaining clips sold separately |
