Description
From a threaded outlet to your watering line
Bring a matching tap or valve into your hose layout with a short, straight connection.
This ¾″ hose barb to ¾″ BSP female adapter has two different jobs: the grey collar joins a male threaded outlet, while the black barbed tail fits inside suitable irrigation hose.
One adapter supplied. The tap, hose and clip shown are not included.
Two sizes to match before you connect
The ¾″ BSP female end screws onto a compatible male thread. Check the thread standard and the mating part’s sealing arrangement before fitting. Do not force a thread that does not engage squarely.
At the other end, suitable ¾″ internal-diameter hose pushes over the barbed tail. In irrigation ranges this fitting is also described by its nominal 20mm barb designation. Check the hose specification and wall material rather than choosing from an outside-diameter measurement alone.
The black tail’s raised barbs sit inside the hose when assembled. The illustration shows the completed connection; the actual product photograph shows the surfaces that the hose covers.
Build the connection without straining the hose
Prepare the threaded joint
Isolate the water and release pressure. Check both threads and the required sealing parts are clean, undamaged and compatible. Start the female collar squarely by hand and follow the mating component’s installation instructions.
Cover the barbed tail
Use sound, suitable hose and push it fully over the insertion tail towards the shoulder. Add a correctly sized retaining clip where your hose system requires it; measure the assembled hose outside diameter when selecting a clip.
Support and check
Route the hose without a tight bend or sideways pull on the threaded outlet. Restore the supply gradually within the system’s limits and inspect both joints. Turn off the water before adjusting or disconnecting the fitting.
Check the connection you need
Does this clip into a garden hose quick connector?
No. One end is a female BSP threaded connection and the other is an insertion barb. It is not a male garden click plug or a female quick-connect hose socket.
Does ¾″ BSP mean a 19mm thread diameter?
No. BSP uses nominal pipe-thread sizes. Match this female end to a ¾″ BSP male fitting rather than comparing the thread with the hose bore. The hose and threaded connections must each be checked separately.
Can it be used as a rotating joint?
Use it as a fixed, supported connection between the threaded part and hose. It is not specified here as a continuously rotating or articulated joint, and it has no valve for controlling the water.
Which hose clip should I use?
Choose retention suitable for your hose material and installation. Measure the hose’s outside diameter when fitted over the tail and select a clip whose adjustment range covers it. The related clip is a separate purchase and is suitable only where its range and type match your assembled hose.
Product information & technical details
| SKU | STR20B34BSPF001 |
|---|---|
| Product type | |
| BSP thread size | 3/4" |
| Thread gender | Female |
| Barb size | 19mm (3/4") |
| Colour | Black |
| Material | Plastic |
|---|---|
| Connection layout | Straight hose tail to female threaded collar |
| Matching threaded part | ¾″ BSP male |
| Assembly colours | Black hosetail with grey collar |
| Supplied quantity | One adapter; hose, clips and mating fittings sold separately |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
