Description
A straight connection for your 25mm pond hose
Join suitable 25mm-bore hose to a matching 1-inch BSP female port with this black plastic male-threaded adapter.
A hexagonal shoulder separates the external thread from the single-size ribbed hosetail. Check both connections before ordering.
One adapter supplied. Hose and clips are separate.
Check the space around the connection
The 70mm overall length and 40mm hosetail section help you plan the fitting position. Leave room for the hose to curve beyond the barb without pulling sideways on the equipment port.
The dimension photo shows two views of one adapter. The 25mm hose size and the nominal 1-inch BSP thread describe separate connections; the thread measures approximately 33.3mm externally.
Match each end before assembly
A few checks keep the connection straightforward.
Confirm the female port
Use a compatible 1-inch BSP female connection. Follow the equipment’s sealing and tightening instructions for plastic fittings, without relying on the hose size to identify the thread.
Seat the 25mm hose
Check that the hose bore and wall profile suit the single-size barb. Choose any securing clip from the fitted outside diameter and hose construction. Clips are sold separately.
Support the hose run
Leave a gentle curve beyond the adapter and keep twisting loads off the port. Retain access to the connection and check both the threaded joint and the hose joint with water after assembly.
Choosing the 25mm male adapter
Does the 1-inch thread measure 25mm across?
No. The 1-inch BSP thread is a nominal pipe size, with an external diameter of approximately 33.3mm. The separate 25mm connection refers to the hose bore. Choose the threaded end by the equipment’s stated BSP size and gender, then check its sealing requirements; do not select the thread from the hose’s inch label alone.
Will this screw onto a male threaded outlet?
No. This adapter has an external male thread and needs a compatible 1-inch BSP female port or fitting. For an equipment outlet with a male thread, choose the appropriate female-threaded hosetail instead. Check the connection specification before ordering, including how the joint is sealed and the tightening guidance for plastic fittings.
What do the 70mm and 40mm dimensions describe?
The fitting is 70mm long overall. The 40mm dimension covers the hosetail section from the shoulder to the tip, as shown in the photograph. The image shows two views of one adapter. These dimensions help with access and layout; also leave space beyond the fitting for your hose bend and for fitting any suitable securing clip.
Is a hose clip included, and which size should I choose?
One bare adapter is supplied; hose clips and hose are separate. A 25mm hose bore does not give its fitted outside diameter. Select a clip that suits the actual outside diameter and hose construction, following the hose and equipment instructions. Support the hose so it does not pull or twist against the fitting, and inspect both joints with water.
Product information & technical details
| SKU | POND25B-1BSPMSTR001 |
|---|---|
| Product type | |
| BSP thread size | 1" |
| Thread gender | Male |
| Barb size | 25mm (1") |
| Colour | Black |
| Material | Plastic |
|---|---|
| Connection layout | Straight 25mm hosetail to 1-inch BSP male thread |
| Overall length | 70mm |
| Hosetail section length | 40mm |
| External thread diameter | Approximately 33.3mm; nominal 1-inch BSP |
| Contents | One adapter; hose, clips and equipment not included |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
