Description
Connect your 25mm hose to a threaded fitting
A black plastic hosetail adapter for suitable 25mm-bore hose and a matching 1-inch BSP male connection.
The female swivel collar engages the equipment thread. At the other end, a single-size ribbed barb carries the hose directly.
One adapter supplied. Hose and clips are separate.
Match the fitting. Position the hose.
Check each connection before you start assembly.
Identify the male thread
The collar needs a compatible 1-inch BSP male fitting. Check the equipment’s sealing requirements and tightening guidance for plastic connections. This adapter cannot screw into a female threaded port.
Seat the 25mm hose
Choose suitable 25mm internal-bore hose with a wall profile that can seat correctly on the barb. Select any clip from the hose’s fitted outside diameter and construction; its bore alone does not give the clip size.
Support and inspect
Allow access to turn the collar and secure the hose, with a gentle supported curve beyond the hosetail. Keep twisting and sideways loads off the fitting, then inspect both completed joints with water before concealing them.
Choosing the 25mm female adapter
Will this fit a 1-inch female port?
No. The threaded collar on this adapter is female and needs a compatible 1-inch BSP male connection. If the equipment has a female port, choose an adapter with the appropriate male thread instead. Check the equipment’s stated BSP size and sealing requirements rather than selecting a fitting from its appearance or the hose’s inch label alone.
Why are the hose and thread both called 1-inch?
They use different size conventions. The hose connection is for suitable 25mm internal-bore hose, commonly called 1-inch. The collar is a nominal 1-inch BSP thread; that does not mean its opening measures 25mm. Confirm the hose bore and the threaded equipment specification independently, including the sealing arrangement.
Do I need to cut the hosetail to use 25mm hose?
This is a single-size 25mm hosetail, not a stepped adapter with smaller sections to cut away. Check that your hose bore and wall construction can seat properly on the barb. Use suitable securing parts for the fitted hose outside diameter and follow the equipment and hose fitting instructions; hose and clips are not included.
Does the swivel collar make this a moving hose joint?
The collar turns during assembly to engage the threaded connection. It is not a stated continuously rotating joint for use while the system runs. Set the hose position during fitting, leave enough slack and support the run so it does not twist or pull against the adapter. Keep both joints accessible and check the finished assembly with water.
Product information & technical details
| SKU | POND25B-1BSPFSTR001 |
|---|---|
| Product type | |
| BSP thread size | 1" |
| Thread gender | Female |
| Barb size | 25mm (1") |
| Colour | Black |
| Material | Plastic |
|---|---|
| Connection layout | Straight 25mm hosetail to 1-inch BSP female thread |
| Collar | Swivel threaded collar for assembly |
| Thread convention | 1-inch BSP is a nominal pipe-thread size, separate from the 25mm hose bore |
| Contents | One adapter; hose, clips and equipment not included |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
