Description
A straight connection for your 100mm hose
Bring suitable 100mm-bore hose to a matching 4-inch BSP female fitting with this black plastic adapter.
A ribbed single-size hosetail and external male thread sit on either side of the shaped shoulder. Check the hose and equipment connection independently before assembly.
One adapter supplied. Hose, clips and equipment are separate.
100mm hose. 4-inch BSP thread.
These are two different connection measurements. The hosetail is for suitable 100mm internal-bore hose; the threaded end follows the nominal BSP size system.
The photograph shows the 4-inch male thread at approximately 113mm across the outside. A threaded fitting chosen simply because an opening measures 100mm will not establish a compatible connection.
Check the equipment’s stated thread and sealing requirements, then match the hose bore and wall profile to the barb.
Leave room to assemble and inspect
Plan access around the thread and the fitted hose.
Identify the female fitting
Use a compatible 4-inch BSP female connection. Follow the equipment instructions for any sealing parts and for tightening plastic fittings; the adapter is supplied on its own.
Seat and secure the hose
Choose suitable 100mm internal-bore hose and check its fit on the hosetail. Select clips from the fitted outside diameter and construction. A 100-120mm clip is suitable only where that measurement and securing method match.
Support the connection
Route and support the hose so its weight does not pull on the equipment port. Leave the joints accessible and inspect them with water before covering the installation.
Before fitting the 100mm adapter
Why does the 4-inch thread measure about 113mm?
BSP uses nominal pipe-thread sizes. The 4-inch male thread is approximately 113mm across its outside, as labelled in the photograph; it is not a 100mm threaded opening. Match it to a compatible 4-inch BSP female fitting and check the equipment’s sealing arrangement. The separate 100mm hosetail is the end intended for the hose.
Which hose clips should I choose?
Measure the hose’s outside diameter after it is seated on the hosetail, then choose a clip range and design suitable for that measurement and hose construction. The suggested 100-120mm clip is an option only where the fitted outside diameter falls within its range. It is not a universal fit for every hose sold as 100mm bore, and clips are separate.
Does the 100mm size establish a pressure or flow rating?
No. It identifies the nominal hose connection size. A system’s operating requirements depend on the pump, hose, fittings and installation, so check the equipment specification before choosing this adapter. The connection dimensions do not establish a pressure, temperature or litres-per-minute rating, nor do they confirm suitability for a particular chemical.
Is this a threaded hose connector or a tank outlet kit?
This is one straight hosetail adapter with a 4-inch BSP male thread at one end and a 100mm hose connection at the other. It is not a complete tank outlet assembly, valve or hose kit. Select any additional sealing, mounting and securing parts to suit the actual equipment and keep the completed hose run supported and accessible for inspection.
Product information & technical details
| SKU | POND100B-4BSPMSTR001 |
|---|---|
| Product type | |
| BSP thread size | 4" |
| Thread gender | Male |
| Barb size | 100mm (4") |
| Colour | Black |
|---|---|
| Material | Plastic |
| Connection layout | Straight 100mm hosetail to 4-inch BSP male thread |
| External thread diameter | Approximately 113mm, as shown in the connection-size photograph |
| Contents | One adapter; hose, clips and equipment not included |
What is BSP?
What is BSP thread size?
BSP (British Standard Pipe) is a nominal pipe-thread size, not a direct measurement of a fitting’s bore or outside diameter. For example, a ½-inch BSP male thread measures about 21mm across its outer thread crests.
These figures are approximate outside diameters of male BSP threads, to help identify the nominal size. They are not inch-to-millimetre unit conversions:
- 3/8" BSP → 16.66 mm
- 1/2" BSP → 20.95 mm
- 3/4" BSP → 26.44 mm
- 1" BSP → 33.25 mm
- 1.25" BSP → 41.91 mm
- 1.5" BSP → 47.80 mm
- 2" BSP → 59.61 mm
- 3" BSP → 87.88 mm
- 4" BSP → 113.03 mm
All our BSP threads are parallel (BSPP, to ISO 228), not tapered.
Measure across the outside of a male thread, then check its pitch and whether it is parallel or tapered. Diameter alone does not confirm compatibility. Check the product’s stated thread specification before connecting.
