Description
A 32mm corner connection with two clips
One 90° barbed elbow and two double-wire hose clips for assembling a right-angle connection in suitable pond hose.
The equal 32mm hosetails join two flexible hose runs. The elbow sets the turn; the clips secure the hose at each end.
Hose and pond equipment are sold separately.
Match the hose and the clips together
Check the hose bore first, then its outside diameter once fitted.
Use the correct hose bore
Both elbow ends are for suitable 32mm internal-bore hose. Check the wall profile and fitting guidance. These equal hosetails are not a reducer or BSP screw connection.
Check the double-wire clips
The supplied clips are designated for 32-36mm corrugated koi pipe. Check their seating on your chosen hose and tighten appropriately, following the hose’s guidance rather than assuming every 32mm hose has the same wall thickness.
Support and inspect the turn
Leave access to both clip screws. Support the hoses beyond the corner so their weight does not pull on the elbow, then check both joints with water before concealing them.
Leave access around the bend
The reference photograph marks 70mm across one leg and a 35mm hosetail section below the bend.
These dimensions describe the elbow as pictured. Your completed connection also needs room for the seated hoses and clip screws, plus access to inspect the joints.
The 1¼-inch hose label is not a BSP thread size. Equipment with a screw port requires a suitable separate hose connection.
Questions about the elbow and clip kit
What is included in this elbow kit?
One black plastic 32mm equal 90° elbow and two double-wire hose clips are supplied. There is no separate hosetail adapter: the two barbed hose connections are part of the elbow itself. Flexible hose, threaded equipment adapters and pond equipment are not included. Match those separately to the needs of your installation.
Will the included clips suit every 32mm hose?
Check the hose construction and fitted outside diameter. The clips are designated for 32-36mm corrugated koi pipe, while the elbow’s 32mm size describes its nominal hose bore. Different wall profiles can give different outside dimensions. Confirm the supplied clips seat and tighten correctly on your hose; the nominal bore alone is not a guarantee of clip fit.
Is the elbow adjustable or threaded?
It is a moulded 90° elbow for suitable flexible hose, not an adjustable swivel or a threaded BSP adapter. Both hosetails are the same nominal 32mm size. Set out the two hose runs to meet that fixed corner without pulling on the body. A threaded pump or filter port needs an appropriate separate hose connection.
How should I allow for the elbow and clip screws?
The reference photo labels 70mm across one leg and 35mm along the hosetail section below the bend. Allow extra room for the hoses to seat and for access to each clip screw. Support the hose runs rather than forcing them into position, follow their fitting instructions and check both completed joints with water before covering the installation.
Product information & technical details
| SKU | POND32BELB001+2DW |
|---|---|
| Product type | |
| Barb size | 32mm (1.25") |
| Kit parts | Plastic Elbow, Doublewire Clip |
| Colour | Black |
| Material | Plastic |
| Connections | Two equal 32mm barbed hosetails |
|---|---|
| Bend angle | 90° fixed right-angle elbow |
| Clip designation | Double-wire clips for 32-36mm corrugated koi pipe; check fitted hose compatibility |
| Reference dimensions | 70mm across one leg; 35mm hosetail below the bend (reference photo) |
| Contents | One black plastic elbow and two double-wire clips; hose and equipment not included |
