Description
Take your 32mm pond hose around a corner
A 90° equal elbow with two matching barbed hosetails for suitable flexible pond hose.
Use the fitting to define a right-angle turn while keeping the connected hose runs supported beyond the bend.
One bare black plastic elbow. Hose, clips and other pond equipment are separate.
Allow space for the fitting and the hose
The reference photograph marks 70mm across one leg and a 35mm hosetail section below the bend.
Those measurements describe the fitting as pictured. The assembled route also needs space for the hose wall, securing clips and access to check both joints.
32mm describes the nominal hose bore. It is not a BSP thread size or the outside diameter used to choose a hose clip.
Make the turn without loading the joints
Set out both hose runs before securing the elbow.
Match the two hoses
Use suitable 32mm internal-bore flexible hose on each end. Check its wall profile and fitting instructions; this equal elbow is not a reducer or threaded equipment adapter.
Keep the runs supported
Use the elbow for the right-angle change in direction, then allow the hose to follow a supported route beyond it. Avoid pulling either run tight or using the fitting to carry hose weight.
Secure and inspect both ends
Choose the securing method for your hose and fitted outside diameter. Keep both joints accessible, then check them with water before hiding the pipework.
Questions about the 32mm elbow
Does 1¼ inch mean a BSP screw connection?
No. On this elbow, 1¼ inch is the nominal inch description associated with the 32mm hose size. Both ends are barbed hosetails for suitable flexible hose, not BSP screw threads. A pump or filter with a threaded port will need an appropriate separate hose connection. Check the equipment thread and hose bore independently.
Is it a reducer between two hose sizes?
It is an equal elbow with nominal 32mm hosetails at both ends. It does not reduce one side to 25mm or adapt directly to 38mm hose. Confirm the hose’s metric internal bore and wall profile before fitting; similar product names or inch descriptions do not establish compatibility with a different hose range.
What do the dimensions in the photograph show?
The reference photograph labels 70mm across one leg, measured from the outside of the bend to the opposite end, and a 35mm hosetail section below the bend. They describe the fitting as pictured, not the complete installed clearance. Allow extra space for both hoses to seat, for any clips and for gradual routing beyond the elbow.
Are hose clips included?
No. This listing supplies one bare black plastic elbow. Choose a suitable securing method separately and select clips for the hose’s outside diameter after it is seated over the barb. The 32mm internal bore alone does not give the required clip range. Support both hose runs and inspect the finished connections with water before concealing them.
Product information & technical details
| SKU | POND32BELB001 |
|---|---|
| Product type | |
| Barb size | 32mm (1.25") |
| Colour | Black |
| Material | Plastic |
| Connections | Two equal 32mm barbed hosetails |
|---|---|
| Bend angle | 90° right-angle elbow |
| Reference dimension | 70mm across one leg (reference photo) |
| Hosetail section | 35mm below the bend (reference photo) |
| Contents | One elbow; hose, clips and equipment not included |
